3HP Marine Power
Compact output for small boats, tender craft, and light-duty fishing applications that value portability. The 70cc engine is configured for stable output across inland and coastal operating conditions.
Outboard Motor2-stroke
NEWTOP Outboard Motor T3
3HP
Compact, portable and easy to maintain, the NEWTOP Outboard Motor T3 combines 3HP two-stroke power with a lightweight 17 kg structure for simple everyday handling. Its built-in fuel tank, tiller steering, manual starting system, and F-N-R gear shift make operation straightforward, while the overall compact design suits dinghies, inflatable boats, and other small boats used on lakes, rivers and short-range near-shore trips.
Key Features
- 3HP two-stroke power with 2.2kW output
- Lightweight 17 kg design for easy carrying and mounting
- Built-in 1.4L fuel tank for convenient everyday use
- Tiller steering with forward, neutral, and reverse gear shift
- CDI ignition system with manual starting
- Manual trim and tilt for straightforward adjustment
- Portable and easy-maintenance design for simple operation
Product Features
More than a basic specification sheet, each NEWTOP outboard motor is built around practical marine use: reliable starting, controlled fuel use, serviceable structure, and stable operation for distributors serving fishing, leisure, and working boats.
2-stroke Operating Character
Simple 2-stroke construction gives fast throttle response, easy service access, and strong power-to-weight value.
Marine-Grade Durability
Anti-corrosion treatment, protected components, and durable exterior finishing support long-term use in wet and salt-exposed environments.
Dealer-Friendly Maintenance
A straightforward servicing layout helps distributors, repair shops, and fleet users reduce downtime during routine inspection and parts replacement.
Specifications
| Max.Output Power | 3.0hp/2.2kW |
| Tansom Height | 15" |
| Engine Type | L1 |
| Displacement | 70cc |
| Bore X Stroke | 46x42mm |
| Ignition System | CDI |
| Max.RPM Range | 4500-5500rpm |
| Idling RPM Range | 1000-1100rpm |
| Fuel Induction System | Carburetor |
| Steering System | Tiller |
| Starting System | Manual |
| Gear Shift | F-N-R |
| Gear Ratio | 2.08 |
| Trim and Tilt | Manual |
| Fuel Tank Capacity | Built-in 1.4L |
| Max. Fuel Consumption | 1.5L/h |
| Lubrication System | 50:1 |
| Gear Oil Capacity | 100cc |
| Rectifier Charging Capacity | None |
| Propeller Options | 7-1/4"X5-1/2"-BL |
| N.W./G.W. | 17kgs |
Factory-Built Quality
NEWTOP controls key production steps from engine assembly to final testing, helping keep product quality consistent for long-term distribution.
